SDR Bulk Fill Flowable Composite: The game changer for posterior composite restorations

Contents:

• Introduction
• The Role of Polymerisation Shrinkage and Shrinkage Stress in composite materials
• Addressing the of Composite Placement Challenges

• Introducing SDR^® Bulk Fill Flowable Composite
• In-vitro Studies on Polymerisation Shrinkage and Marginal Adaptation of SDR^® Bulk Fill Flowable Composite
• Clinical Study Results
• Conclusion

Introduction:

The Rise of Composite Resin and Environmental Concerns about Amalgam

Over the past 40 years, composite resin has outpaced amalgam in dentistry extensively due to the demand for more aesthetic restorations worldwide. Additionally, environmental effects of dental amalgam resulted in either a decline or a ban in many countries and may eventually phase out in response to the Minamata convention.¹

Composite Resin Failure and Risk of Secondary Caries

The problem with composite resins is that according to a recent systematic review, they have approximately double the failure rate of amalgam restorations.² Restoration fracture does not seem to be greater with composite resin restorations, but the risk of developing secondary caries is significantly higher. The major questions when evaluating the etiologies of failure are why there are more failures with composite than amalgam and what are the reasons for greater recurrent caries.

Addressing the Challenges with Composite Resin

Dental manufacturers have made developments in alternative materials, the composites resins, to address these questions with improvements in filler composition, photo-initiators, and mechanical properties to improve wear and durability.^3,4

What are the Challenges:

The Role of Polymerisation Shrinkage and Shrinkage Stress

The process of photo-polymerisation results in the resin monomers connecting to make larger molecules called polymers which also join together forming a continuous network. However, the composite shrinks rapidly via this free radical process resulting in volumetric shrinkage in the range of 2-6% pending the type of composite used. When the composite is placed in a deep preparation after adhesive placement and is photo-polymerised, it has a limited ability to relax and flow creating stress within the material as well as the tooth-restoration interface that may result in debonding when the shrinkage stress is greater than the bond strength of the adhesive. Additionally, these stresses may continue and damage the restoration-adhesive interface during masticatory function.⁵ The net result is a plethora of clinical complications including cuspal deflection, enamel cracking and larger marginal gap formation leading to greater bacterial colonisation, secondary or recurrent caries, post operative sensitivity, pulpal inflammation and expedited failure.⁶ The common hypothesis for many years was that as photo- polymerisation was occurring the composite was shrinking towards the light. However, additional studies over the years postulated the direction was the result of boundary conditions or the ratio of bonded to unbonded cavity walls (C-factor) and less affected by the relation toward the light.^5,7,8

Addressing the Challenges:


Different Approaches to Composite Placement and Light Curing Protocols

Based on the complexities with polymerisation shrinkage, different approaches to composite placement have been proposed to reduce composite resin failure. Different light curing protocols such as soft-start, ramp cure and pulse delay have limited clinical evidence to suggest improved outcomes over the conventional light curing devices.⁵

The first-generation flowable composites were touted to suggest their low viscosity would create better adaptation to the dentin and help reduce effects of shrinkage based on their low modulus of elasticity. However, their elevated volumetric shrinkage from a low filler content and weak mechanical properties resulted in unfavourable clinical results compared to existing alternatives.⁹ Several incremental placement protocols were presented to reduce the C-factor by minimising the amount of composite in contact within the cavity walls and potentially allowing for more flow of the composite.

However, pending on the protocol used, incremental filling may not reduce polymerisation stress to the tooth.¹⁰ Another disadvantage of multiple increments of 4 or more, is the increased time to do the procedure. If not using a rubber dam, the error potential increases making the procedure more technique sensitive, less efficient and less proficient.

Advances of Composites: Introducing Bulk-Fill materials

To answer this procedural risk, bulk-fill composite materials were introduced by dental manufacturers, starting in the late 1990’s (e.g. Surefil^® Composite by Dentsply Sirona), to expedite the extended procedure times of incremental filling techniques and curing by modifying translucencies and photo-initiators providing an enhanced depth of cure and thus allow the placement of larger increments.

To manage shrinkage and stress build-up, those bulk-fill materials featured a high filler content, thereby minimising volumetric shrinkage, and consequently require the dental practitioner to pack the material into the cavity to create the required adaptation. More recent materials of this category of packable/sculptable bulk fill composites were stated to be able to be used in up to 5 mm increments with lower polymerisation shrinkage stress due to decreased filler amount or increased filler size and incorporation of stress modifiers.^11,12

Since 2009 however, bulk-fill composites have been subdivided into two groups based on viscosity. In addition to the high viscosity or packable/sculptable bulk-fills, low viscosity or flowable bulk-fills emerged as a new material category, with lower filler contents and weaker mechanical properties. Those materials are generally used as dentin replacements only requiring a 2-mm enamel capping layer of traditional composite.¹²

The polymerisation shrinkage and polymerisation shrinkage stresses of both types of bulk-fill composites have been analysed and compared in several studies. ^{11,13,14,15,16,17,18,19,20,21,22,23}

What was concluded and stood out prominently from all the studies referenced was that one flowable bulk-fill chemistry had the lowest polymerisation shrinkage stress - SDR^® Bulk Fill Flowable Composite.

Introducing SDR® Bulk Fill Flowable:

Features and Handling Characteristics

SDR^® Bulk Fill Flowable Composite is a one-component, fluoride-containing, visible light cured, radiopaque composite. SDR^® Bulk Fill Flowable Composite has handling characteristics typical of a flowable composite, however, can be placed in 4 mm increments with minimal polymerisation stress. SDR^® Bulk Fill Flowable Composite has a self-levelling feature that allows intimate adaptation to the prepared cavity walls.

When used as a base/liner material in Class I and II restorations, it is designed to be overlayed with a methacrylate-based universal/posterior composite for replacing missing occlusal/facial enamel.  It is also suitable as a stand-alone restorative material in conservative Class I, Class III and V restorations without a separate capping being applied on top. To ensure aesthetic appearance in Class III and V restorations, the shade range has been expanded to A1, A2 and A3 shades in addition to the universal shade.


Lower Polymerisation Shrinkage Stress due to Unique UDMA Structure

The SDR^® Bulk Fill Flowable Technology exhibits a patented urethane dimethacrylate structure (UDMA) that allows for a volumetric shrinkage of only 3.5%, which puts it on the low end in overall shrinkage compared to other flowable composites. Though, lower volumetric shrinkage can contribute to overall lower polymerisation stress reduction, it is the polymerisation pattern and the patented and therefore unique UDMA structure that is key to stress reduction.

Compared to conventional resin systems, the SDR^® Bulk Fill Flowable Composite forms large molecular structures upon polymerisation that, according to the manufacturer, include a chemical moiety called “polymerisation modulator”. The high molecular weight and the conformational flexibility around the centred modulator impart optimised flexibility and network structure to SDR^® Bulk Fill Flowable Composite. The SDR^® Bulk Fill Flowable Composite Technology can dissipate more energy during polymerisation, thereby inherently reducing the shrinkage stress. As a result, SDR^® Bulk Fill Flowable Composite provides an approximately 20% reduction in volumetric shrinkage and almost an 80% reduction in polymerisation stress compared to conventional methacrylate resins.

Current SDR^® Bulk Fill Flowable Composite Material characteristics

In comparison of the original chemistry, the resin matrix and filler paste have been modified in the currently available SDR^® Bulk Fill Flowable Products (SDR^® flow+ / SDR^® Plus). The filler load has been increased by 2.5% pts to strengthen the material, improve its radiopacity and reduce its wear.

The previous glass filler has been partially replaced by an alternative filler which provides higher strength. The resin was also re-formulated to adjust to the overall consistency of the new filler loading and retain the flowability and self-levelling, key characteristics of SDR^® Bulk Fill Flowable Composite. The patented and therefore unique characteristics of the first generation SDR^® Bulk Fill Flowable Material were preserved while increasing the wear resistance to the level of standard flowable composites and the radiopacity by approximately 20% to 2.6 mm Al.

Comparing SDR® Bulk Fill Flowable Composite:

In-vitro Studies on Polymerisation Shrinkage and Marginal Adaptation

For in-vitro studies, new technologies have been introduced to assess marginal adaptation of different types of composites in Class I and II posterior composite restorations. Microcomputed tomography (μ-CT) allows for non-destructive evaluation of the restorative interface in two and three dimensions and can measure volumetrically in microns the marginal integrity and internal adaptation of the restorative materials studied.^8,19,27

A recent study²⁸ evaluated three bulk-fill composite resins, SDR^® Bulk Fill Flowable, 3M™ Filtek™ One Bulk Fill† and Tetric^®N-Ceram Bulk Fill† against a conventional composite resin Filtek™ Z350† in caries free and crack free human molars prepared with a MOD restoration. The teeth were thermocyled and cyclic loaded to mimic ageing and stresses in the oral cavity during function. Micro-CT was performed on each sample to measure the interfacial gap at the restorative interface.

The results demonstrated that SDR^® Bulk Fill Flowable had the smallest gap volume of all tested composite resins. An additional in-vitro Micro-CT study¹⁹ on Class I restorations concluded SDR^® Bulk Fill Flowable exhibited less volumetric polymerisation shrinkage compared with the other flowable groups, Permaflo™†, Filtek™ Bulk-fill flow†, and Vertise™ flow†.

Swept-Source Optical Coherence Tomography (SS-OCT) is another in-vitro technology developed to visualise how composites behave while undergoing light polymerisation using real-time video display. Two studies^29,30 concluded SDR^® Bulk Fill Flowable Composite had a slower polymerisation rate and a delayed gel point of resin matrix increasing its flow capacity as demonstrated by a lower incidence of voids and better internal dentin adaptation at both 2 mm and 4 mm depths compared to a conventional flowable composite. Another SS-OCT study³¹ demonstrated that SDR^® Bulk Fill Flowable Composite had a low shrinkage stress making it ideal as an intermediate dentin replacement layer for better internal adaptation compared to other bulk-fill composites.

A biocompatibility study³² found that only SDR^® Bulk Fill Flowable and one other bulk fill composite demonstrated cell viability above 70% at a 4mm increment, whereas two standard composites, two bulk-fill pre-reacted glass ionomer composites and one other bulk-fill composite showed lower cell viability.

In studies assessing the degree of conversion and depth of cure when light curing bulk fill composites, SDR^® Bulk Fill Flowable material showed significantly higher conversion degrees at the bottom and top surface than the other composites tested. Shorter curing times (10 seconds) significantly reduced the polymerisation of Filtek™ Bulk Fill† and x-tra base†. SDR^® Bulk Fill Flowable demonstrated high polymerisation in 4 mm thick bulks reaching the conversion degree of 2 mm thick composite layers. SDR^® Bulk Fill Flowable, in the manufacturer’s light-curing time, cured properly in 4 mm. Higher radiant exposure of SDR^® Bulk Fill Flowable had no adverse effect on its polymerisation shrinkage. Flowable bulk-fill composites like SDR^® Bulk Fill Flowable performed better regarding polymerisation efficiency at 10 seconds compared to high viscosity bulk-fill composites like SonicFill™† that required 20 seconds.^33,34,35,36

The Benefits of SDR^® Bulk Fill Flowable Composite for Class II Restorations

At the onset of research on SDR^® Bulk Fill Flowable Composite, several studies demonstrated its ability to bond well to the cavity floor in high C-factor restorations at 4 mm increments.^24,25,26 In the direct Class II posterior composite restoration, the goal for the clinician is to apply materials that reduce polymerisation shrinkage and shrinkage stress and work effectively on enamel, as well as in the proximal box of deep restorations where dentin and cementum become primary concerns for long-term success. Therefore, the type of composite resin used in the proximal box may play a critical role in the marginal adaptation of a Class II posterior composite restoration.

Using SDR^® Bulk Fill Flowable Material in the open-sandwich technique for placement of a Class II posterior composite restoration allows a layer placed as dentin replacement extending from the gingival box floor up to 4 mm. With the remaining top or enamel layer of at least 2 mm all proximal margins exposed to the oral cavity are sealed, which is of primary concern for long-term clinical success.

Clinical Trials and Results:

Retrospective and Randomised Controlled Studies

Clinical trials of Class II posterior composites published using SDR^® Bulk Fill Flowable Material have been both retrospective and randomised controlled in methodology. A recent retrospective study³⁷ of SDR^® Bulk Fill Flowable Composite used in two increments as a 4 mm dentin increment with a 2 mm enamel layer of a traditional composite versus a traditional composite used in three 2 mm increments resulted in the SDR^® Bulk Fill Flowable group performing better over a 3-year period. The authors concluded the use of SDR^® Bulk Fill Flowable Composite may provide a reduced procedure time for posterior composites over conventional composites and extended incremental techniques.

4-year randomised prospective split-mouth evaluation

A recent 4-year randomised prospective split-mouth evaluation of bulk fill flowable composites in Class II posterior composite restorations compared a conventional microhybrid composite resin (Amelogen Plus†, Ultradent†) against a flowable bulk-fill and nanoparticulate composite resins (Filtek™ Bulk Fill Flow† + Filtek™ Z350XT†, 3M™/Espe†); and flowable bulk-fill and microhybrid composite resins, (SDR^® Bulk Fill Flowable + TPH^®3 Composite, Dentsply Sirona). The results demonstrated that the SDR^® Bulk Fill Flowable/ TPH^®3 Composite group had better performance for wear and surface staining than the other groups.³⁸


6-year randomised controlled study

A 6-year randomised controlled study³⁹ evaluated a flowable resin composite bulk-fill technique in posterior restorations and compared it with a conventional 2-mm composite layering technique for Class I and II posterior composite restorations. Thirty-eight pairs of Class II restorations and 15 pairs of Class I restorations were placed in 38 adults. In the first cavity of each pair, the flowable resin composite (SDR^® Bulk Fill Flowable) was placed, in bulk increments of up to 4 mm. The occlusal aspect was finished with a layer of nanohybrid resin composite. In the second cavity of each pair, the hybrid resin composite was placed in 2-mm increments. After 6 years, 72 Class II restorations and 26 Class I restorations could be evaluated. Six failed Class II molar restorations, three in each group, were observed, resulting in a success rate of 93.9% for all restorations and an annual failure rate (AFR) of 1.0% for both groups. The main reason for failure was resin composite fracture and not secondary caries.

The investigators were able to replicate those results in a 5-year randomised controlled study⁴¹ that followed a similar protocol with 38 pairs of Class I and 62 pairs of Class II restorations (first restoration with 4 mm SDR^® Bulk Fill Flowable Composite + nano-hybrid resin, second restoration with nano-hybrid resin composite in 2 mm increments) placed in 86 patients.

After 5 years, 68 Class I and 115 Class II restorations could be evaluated. Ten restorations failed with four in the SDR^® Bulk Fill Flowable Composite and six in the control group due to tooth fracture and secondary caries, resulting in a success rate of 94.5% for all restorations and an annual failure rate (AFR) of 1.1% for the SDR^® Bulk Fill Flowable group and 1.3% for the control group.

Conclusion:

SDR^® Bulk Fill Flowable Composite as a Game-Changer in Dental Restorations

Developed in 2009, flowable bulk fill composites with SDR^® Bulk Fill Flowable Composite technology became the first composite resin that allowed 4mm bulk placement in flowable nature. Now, over 13 years later, SDR^® Bulk Fill Flowable Composite has established itself as the most important development in composite resin technology and biggest game changer for posterior composite restorations.


Improved Marginal Integrity, Reduced Shrinkage Stress, and Enhanced Longevity

The success of a Class II composite resin is dependent upon placing a material in the most constricted area of the restoration, the gingival box. Placement of SDR^® Bulk Fill Flowable Composite not only seals that gingival margin better than conventional and other bulk fill composites but in combination with only 1-2 increments of the enamel top layer with a nano-hybrid composite can expedite the technique and oral environment sensitive procedure compared to traditional multiple small increment protocols.⁴⁰

Many materials have tried to imitate the SDR^® Bulk Fill Flowable Composite but no other dental material has been studied as extensively or ever duplicated the successful clinical results of over a hundred million restorations produced using SDR^® Bulk Fill Flowable Composite technology. In-vitro studies and clinical trials have clearly demonstrated that no other material available to dentists all over the world is better than SDR^® Bulk Fill Flowable Composite as the true bulk fill dentin replacement material for every composite restoration.
